Specification：
| Max.size (A+B) X2 |
3600mm |
Min.length A |
250 mm |
| Min.size (A+B) X2 |
740mm |
Max.height D |
2000 mm |
| Max.size (C+D+C) |
3000mm |
Min.height D |
150 mm |
| Min.size (C+D+C) |
250mm |
Max.nail tongue width E |
40 mm |
| Min.swing top C |
50mm |
Max.feeding height |
900 mm |
| Max.swing top C |
560 mm |
Machine width |
2850 mm |
| Max.width B |
760 mm |
Machine weight (T) |
1.6 |
| Min.width B |
120 mm |
Speed(nails/min) |
600 |
| Max.length A |
1120 mm |
Number of nails |
1-99 |
Feeding section：
● French imported Schneider double servo driving motor with high precision, mechanical transmission parts reduced as well as the mechanical failures.
● Electrical back baffle, stepper motor driving, high size precision, and can change more convenient and quickly.
● It can nail single nail,double nail, strengthen nail (double nail both sides, and the middle is single mail) in one-time, can be suitable for different kinds of customer requirements of nails.
● Speed: 600nails/min
● Automatic wire feeding system, 20kg flat wire, which can save time.
● The whole machine can order adjustment, and save 1000 orders. |
